Introduction of vertical ring die pellet machine and features

Brief Introduction:

pellet machine,also called pellet mill, pelletizer..... there are different types of pellet machine like wood pellet machine and feed pellet machine.

The vertical ring die pellet machine absorbs the advantages of the horizontal ring die pellet machine and the flat die pellet machine abandoned the hornzontal ring die pelet machine low pressure , mold is easy to burst. flat die pelet machine low capacityequipment failure hich , then research and deveiccment the biomassfuel pellet machine , Presses the eucalyptus. pine, birch.poplar, fruit and crop straws and bamboo sawdust into pellets.

The Features of Pellet Machine:

1. The mold is vertical, vertical feeding material, no arching, easy to dissipate heat

2. 2.Mold stationary vertical installation, the machine is easy to fix, operation smoothly.

3. 3.Roller rotating ,the centrifugal force generated causes the material to be evenly distributed around

4. 4.Double-layer die, two layers both can be used, to reduce costs and increase efficiency.

******************************************************************************************************************************************************************************

8 TH GENERATION (250kw) XGJ850 Pellet Mill

- Output: 3-4T/H

-Power(kw):250+3+0.55+1.5+3

-Pellet diameter: 6,8,10mm

-Weight of machine (Ton): 14tons

-Dimension(mm): 2650×1850×2100

- New generation Gear reducer system

Whole set include: *Fan Blower 3kw *Bag dust collector, *Automatic roller lubrication pump *Electric control Box *Frequency Device
