Introduction of Dust Removal

There are three types of dust removal methods: cyclone separator dust removal, bag dust removal, and pulse dust removal.

Bag dust removal: Dust containing gas is blown into the bag of the dust collector under the action of the fan, and the wind is filtered from the bag to the outside of the bag, while the dust is trapped inside the bag, thus achieving the separation of wind and dust. It requires manual cleaning from time to time.

Pulse dust removal: Dust containing gas is sucked into the box of the pulse dust collector under the action of a fan, filtered by multiple sets of cloth bags, and the wind enters the cloth bags with a skeleton, which are discharged from the box through pipelines. The dust is adsorbed on the outer surface of the cloth bags, and under the action of an air compressor, pulse high-pressure gas is regularly sprayed on each cloth bag, causing it to instantly expand and shake off the dust into the ash hopper. This process is a separation of wind and dust, And the process of automatic dust removal.

Comparison:

Cyclone dust removal: It belongs to simple dust removal, and the general dust removal effect can reach 70%.

Bag dust removal: dust removal capacity between 80-90%.

There is no significant difference between pulse dust removal and bag dust removal. The effect can only be seen when there is air flow inside two hours and the bag is impacted. Dust removal capacity between 80-90%, with self cleaning function.

Cyclone+bag dust removal+water dust removal, with an effect of 95-99%. Very expensive, the cost is too high, and it is generally not recommended.
